Power HD M8P Low Profile HV Coreless Servo 1/12 above

RM296.00

Power HD M8P Low Profile HV Coreless Servo 1/12 above

1 in stock

SKU: HD-M8P Category:

Power HD M8P Low Profile HV Coreless Servo 1/12 above



Torque(4.8V): 4.3 kg-cm (59.7 oz/in)
Torque(6.0V): 6.3 kg-cm (87.5 oz/in)
Torque(7.4V): 7.6 kg-cm (105.5 oz/in)
Torque(8.4V): 8.5 kg-cm (118.0 oz/in)
Speed: 0.10 sec (4.8V) │ 0.079 sec (6.0V)
Speed: 0.068 sec (7.4V) │ 0.058 sec (8.4V)
Operating Voltage:4.8 ~ 8.4 DC Volts
Weight: 28.6 g (1.0 oz)
Motor Type:Coreless Motor
Gear Type: Titanium & Steel
Operating Temperature: -20℃~60℃
Working frequency:1520μs / 333hz
Size:28.5 x 13.4 x 29.0 mm ( 1.12 x 0.53 x 1.14 in)

Weight 0.40 kg
Dimensions 25.00 × 25.00 × 20.00 cm
